Description
LKMSM-HF
Armoured power cable with extruded filler 0,6/1kV
Application: For fixed installation in most areas and on open deck in ships and off shore units.
Main characteristics | |
Rated voltage | AC 0,6/1kV (1,2kV) DC 0,9/1,5kV (if voltage to earth does not exceed 0,9kV) |
Flame-retardant | IEC 60332-1-2 -test for single insulated wire and cable IEC 60332-3-22 -test for bunched wires and cables, category A |
Halogen-free | IEC 60754 series |
Smoke emission | IEC 61034 series |
Oil resistance (only SHF2) | IEC 60811-404 conditions according to 60092-360/SHF2 |
Temperature rating: | Maximum conductor temperature + 90 °C Fixed installation -40 °C to +80 °C Minimum recommended installation temperature -15 °C |
For details see general information section |
Part number Normal |
G-type | Number of conductors & cross-section n x mm2 |
Cross-section of armour mm2 |
Nominal outer diameter mm |
Approximate weight kg/km |
Current Rating A at +45°C |
Min. bending radius fixed installation mm |
27232 | – | 2×1,5 | 4,9 | 11,5 | 190 | 20 | 70 |
27234 | – | 2×2,5 | 5,4 | 12,5 | 225 | 26 | 75 |
27236 | – | 2×4 | 6,0 | 14,0 | 285 | 34 | 85 |
27238 | – | 2×6 | 9,2 | 15,5 | 415 | 44 | 90 |
27240 | – | 2×10 | 10,7 | 17,5 | 565 | 61 | 105 |
27243 | – | 2×16 Flex | 12,6 | 20,5 | 735 | 80 | 120 |
27245 | – | 2×25 Flex | 15,6 | 24,5 | 1070 | 105 | 150 |
27247 | – | 2×35 Flex | 16,8 | 26,5 | 1350 | 130 | 160 |
27249 | – | 2×50 Flex | 19,6 | 30,0 | 1800 | 167 | 180 |
27264 | 27266 | 3×1,5 | 5,3 | 12,0 | 220 | 16 | 75 |
27268 | 27270 | 3×2,5 | 5,7 | 13,5 | 270 | 21 | 80 |
27272 | 27274 | 3×4 | 8,7 | 15,0 | 360 | 28 | 90 |
27276 | 27278 | 3×6 | 9,7 | 16,0 | 485 | 36 | 95 |
27280 | 27282 | 3×10 | 11,5 | 18,5 | 675 | 50 | 110 |
27285 | 27287 | 3×16 Flex | 13,4 | 22,0 | 905 | 66 | 130 |
27289 | 27291 | 3×25 Flex | 16,7 | 26,0 | 1310 | 86 | 155 |
27293 | 27295 | 3×35 Flex | 18,4 | 28,0 | 1665 | 107 | 170 |
27297 | 27299 | 3×50 Flex | 21,0 | 32,5 | 2250 | 137 | 195 |
27301 | 27303 | 3×70 Flex | 24,7 | 37,5 | 3095 | 168 | 225 |
27305 | 27307 | 3×95 Flex | 38,8 | 42,0 | 4020 | 199 | 250 |
27309 | 27311 | 3×120 Flex | 41,9 | 46,5 | 4990 | 232 | 280 |
27313 | 27315 | 3×150 Flex | 50,2 | 53,0 | 6275 | 267 | 320 |
27328 | 27330 | 4×1,5 | 5,6 | 13,0 | 255 | 16 | 80 |
27332 | 27334 | 4×2,5 | 6,3 | 14,5 | 315 | 21 | 85 |
27336 | 27338 | 4×4 | 9,5 | 16,0 | 425 | 28 | 95 |
27340 | 27342 | 4×6 | 10,6 | 17,5 | 580 | 36 | 105 |
27344 | 27346 | 4×10 | 12,6 | 20,0 | 815 | 50 | 120 |
27349 | 27351 | 4×16 Flex | 14,8 | 23,5 | 1085 | 66 | 140 |
27353 | 27355 | 4×25 Flex | 18,5 | 28,5 | 1595 | 86 | 170 |
27357 | 27359 | 4×35 Flex | 19,9 | 31,0 | 2055 | 107 | 185 |
27361 | 27363 | 4×50 Flex | 23,2 | 35,5 | 2775 | 137 | 215 |
27365 | 27367 | 4×70 Flex | 37,8 | 42,0 | 3945 | 168 | 250 |
27369 | 27371 | 4×95 Flex | 41,7 | 46,5 | 5010 | 199 | 280 |
27373 | 27375 | 4×120 Flex | 46,9 | 51,5 | 6240 | 232 | 310 |
27392 | 27394 | 5×1,5 | 6,1 | 14,0 | 295 | 13 | 85 |
27396 | 27398 | 5×2,5 | 9,3 | 15,5 | 390 | 17 | 95 |
27400 | 27402 | 5×4 | 10,4 | 17,0 | 505 | 23 | 105 |
27404 | 27406 | 5×6 | 11,6 | 19,0 | 680 | 30 | 115 |
27408 | 27410 | 5×10 | 13,8 | 22,0 | 975 | 42 | 130 |
27413 | 27415 | 5×16 Flex | 16,3 | 25,5 | 1320 | 55 | 155 |
27417 | 27419 | 5×25 Flex | 20,3 | 31,0 | 1930 | 71 | 185 |
Other sizes on request.
G-type is with yellow/green earth conductor and marking on sheath is, for example, 3G1,5
Part number for oil resistant SHF2 cable:
4 + code from above table ➞ 4xxxxx
