2YSL(St)CYK
DownloadDatasheet PDF 2YSL(St)CYK EMC connecting cable APPLICATION Shielded motor connection cable for frequency converters. The shield prevents the unauthorised influence... read more
Description
2YSL(St)CYK
EMC connecting cable
APPLICATION
Shielded motor connection cable for frequency converters. The shield prevents the unauthorised influence of electromagnetic interferences. The optimum shielding enables frequency converters to be operated fault free. The areas of use include machine tools, industry robots, air conditioning systems, pump systems and handling equipment. Suitable for use in dry and wet rooms and outdoors.
| Structure | |
| Conductor | Copper wire, bare |
| Cores | Polyethylene (PE) insulation |
| Shield | Aluminium foil, 100% tin-plated copper wires |
| Outer sheath | PVC, black |
| Technical data | |
| Nominal voltage | 600 V/1000 V |
| Test voltage | 4000 V |
| Insulation resistance | 20 MOhm x km |
| Conductor resistance | According to DIN VDE 0295 class 5; IEC228 class 5 |
| Temperature range | Moving -5°C to +70°C |
| Temperature range | Fixed installation -40°C to +70°C |
| Min. bending radius | 20 x cable diameter |
| Product description | Cu weight | Outer Ø (mm) | Weight (kg/km) |
| 2YSL(St)CYK-J 3×1.5 + 3×0.25 | 86 | 12 | 215 |
| 2YSL(St)CYK-J 3×2.5 + 3×0.5 | 144 | 13 | 265 |
| 2YSL(St)CYK-J 3×4 + 3×0.75 | 224 | 15 | 350 |
| 2YSL(St)CYK-J 3×6 + 3×1 | 298 | 16 | 430 |
| 2YSL(St)CYK-J 3×10 + 3×1.5 | 491 | 21 | 695 |
| 2YSL(St)CYK-J 3×16 + 3×2.5 | 723 | 24 | 925 |
| 2YSL(St)CYK-J 3×25 + 3×4 | 1.138 | 28 | 1350 |
| 2YSL(St)CYK-J 3×35 + 3×6 | 1.535 | 30 | 1760 |
| 2YSL(St)CYK-J 3×50 + 3×10 | 2.208 | 35 | 2550 |
| 2YSL(St)CYK-J 3×70 + 3×10 | 2.871 | 39 | 3210 |
| 2YSL(St)CYK-J 3×95 + 3×16 | 3.953 | 42 | 4110 |
| 2YSL(St)CYK-J 3×120 + 3×16 | 4.836 | 47 | 4925 |
| 2YSL(St)CYK-J 3×150 + 3×25 | 5.412 | 52 | 6200 |
| 2YSL(St)CYK-J 3×185 + 3×35 | 6.969 | 57 | 7500 |
| 2YSL(St)CYK-J 3×240 + 3×50 | 8.540 | 62 | 9610 |
SPECIAL FEATURES
Sheath colour: Black
