9YC11Y cl.6
Cable Structure:
- Bare copper, bunch stranded to DIN VDE 0295 cl.6, col4 and IEC 60228 cl.6, extra fine wire conductors
- Black cores with continuous white numbering
- Green/Yellow earth core in the outer layer from 3 cores and above
- Special core insulation, modified PP
- Cores stranded in layers with optimal selected lay-length
- Special core wrapping over each layer
- Special full-polyurethane outer jacked TMPU to DIN EN 50363-10-2, black mat to prevent adhesion
- Optimized screening braiding of tinned copper wires
Technical Data:
- Nom. Voltage: 300/500V
- Test Voltage: 4000V
- Temperature Range:
– Flexing: -30°C……+80°C
– Fixed: -40°C……+80°C - Temperature at conductor: +70°C in operation; +150°C in case of short circuit
- Flame retardant: acc. to Din EN 60332-1-2
- Oil Resistant: acc. to DIN EN 50363-10-2 / DIN EN 60811-2-1
- Bending radius: 7,5 x diameter
Application
The special cable for drag chains are used for permanent flexible applications in machineries, machine tools, multi-shift, machinery parts, for movable automated and robot technics operation.
| Dimension | Outerdiameter | Copper weight | Total |
| N x mm | mm | kg/km | kg/km |
| 4 G 0,75 mm² | 7,4 | 58 | 114 |
| 7 G 0,75 mm² | 8,7 | 85,5 | 167 |
| 12 G 0,75 mm² | 10,7 | 126 | 235 |
| 2 x 1,5 mm² | 7,7 | 58 | 116 |
| 3 G 1,5 mm² | 8,5 | 76 | 139 |
| 4 G 1,5 mm² | 9,1 | 91,3 | 157 |
| 7 G 1,5 mm² | 12,3 | 145 | 252 |
| 12 G 1,5 mm² | 13,7 | 242,2 | 419 |
| 3 G 2,5 mm² | 9,6 | 110 | 197 |
| 4 G 2,5 mm² | 10,8 | 135,5 | 233 |
