PURWIL EPR/PUR, single-core
DownloadDatasheet PDF PURWIL EPR/PUR, single-core Flexible low voltage cables 23_1_0 CH-S1BQ-F Flexible single-core polyurethane cable (EPR/PUR) Application Device and apparatus... read more
Description
PURWIL EPR/PUR, single-core
Flexible low voltage cables
23_1_0
CH-S1BQ-F
Flexible single-core polyurethane cable (EPR/PUR)
Application
- Device and apparatus construction
- Machine industry
- Secondary output for transformers
Construction
- Copper cord flex, cl. 5 (IEC 60228) finely stranded
- EPR insulation
- Sheath PUR
Description
- Designed pursuant to standard SEV TP 20B/3C
- Core designed acc. to CENELEC HD 22.12
- Nominal voltage 1000 V
- Min. bending radius 10x D (D = cable-Ø)
- Halogen-free
Temperature range
-40°C…+90°C
Jacket colour
Grey similar to RAL 7011
Standards
- SEV TP20B/3C
- IEC 60754-1 halogen free
Technical data
| Cross-section mm² | Part no. | Conductor design | Ø d1 approx. mm | Ø d2 approx. mm | Ø D approx. mm | Cu-number kg/km | Weight kg/km | Insulation |
| 1×2.5, vzi | 23027 | L | 2.1 | 5.1 | 7.1 | 24.00 | 65.0 | orange |
| 1×4.0, vzi | 23804 | L | 2.7 | 6.0 | 38.40 | 63.0 | without | |
| 1×16 | 23820 | L | 5.8 | 8.2 | 10.2 | 153.60 | 205.0 | black |
| 1×16 | 23821 | PE | 5.8 | 8.2 | 10.2 | 153.60 | 205.0 | yellow/green |
| 1×25 | 23825 | L | 7.2 | 10.0 | 12.2 | 240.00 | 303.0 | black |
| 1×25 | 23826 | PE | 7.2 | 10.0 | 12.2 | 240.00 | 303.0 | yellow/green |
| 1×50 | 23835 | L | 10.4 | 13.6 | 16.0 | 480.00 | 568.0 | black |
| 1×50 | 23836 | PE | 10.4 | 13.6 | 16.0 | 480.00 | 568.0 | yellow/green |
| 1×70 | 23840 | L | 12.2 | 15.4 | 18.0 | 672.00 | 770.0 | black |
| 1×70 | 23841 | PE | 12.2 | 15.4 | 18.0 | 672.00 | 770.0 | yellow/green |
| 1×95 | 23068 | L | 14.2 | 17.8 | 20.6 | 912.00 | 1054.0 | black |
| 1×95 | 23846 | PE | 14.2 | 17.8 | 20.6 | 912.00 | 1054.0 | yellow/green |
| 1×120 | 23850 | L | 16.5 | 20.1 | 23.1 | 1152.00 | 1299.0 | black |
| 1×120 | 23851 | PE | 16.5 | 20.1 | 23.1 | 1152.00 | 1299.0 | yellow/green |
| 1×150 | 23855 | L | 17.8 | 21.8 | 25.0 | 1440.00 | 1578.0 | black |
| 1×150 | 23856 | PE | 17.8 | 21.8 | 25.0 | 1440.00 | 1578.0 | yellow/green |
| 1×185 | 23860 | L | 19.8 | 24.2 | 27.6 | 1776.00 | 1977.0 | black |
| 1×185 | 23861 | PE | 19.8 | 24.2 | 27.6 | 1776.00 | 1977.0 | yellow/green |
| 1×240 | 23865 | L | 23.0 | 27.8 | 31.6 | 2304.00 | 2533.0 | black |
| 1×240 | 23867 | PE | 23.0 | 27.8 | 31.6 | 2304.00 | 2533.0 | yellow/green |
| 1×300 | 23870 | L | 25.0 | 30.0 | 34.4 | 2880.00 | 3135.0 | black |
| 1×300 | 23869 | PE | 25.0 | 30.0 | 34.4 | 2880.00 | 3135.0 | yellow/green |
| 1×400 | 23868 | L | 28.0 | 33.6 | 38.2 | 3840.00 | 4022.0 | black |
